Wampfler 0815 SingleFlexLine: Compact Single-Pole Conductor Rail for Curving Applications and Limited Installation Space from 32A to 100A
Wampfler 0815 SingleFlexLine is a compact single-pole insulated conductor rail system engineered for curving applications, ring arrangements, and installations where limited space between conductor rail poles is a primary constraint. The 0815 is the space-optimized variant of the Wampfler SingleFlexLine family, sharing the 0811's flexible curving capability while delivering a more compact pole profile with an optimized phase distance of 12mm or 14mm that makes it the correct specification for US installations where available space between conductor poles is insufficient for the standard 0811 profile. Crane-Controls.com stocks Wampfler 0815 components for US buyers specifying compact Wampfler conductor rail for monorail, specialized machine, sorter, and small parts warehouse applications.
The 0815 SingleFlexLine is rated from 32A through 100A at 100% duty cycle with a nominal voltage of 690V and standard rail length of 4000mm. Its 9.6 x 15.2mm pole profile is the most compact in the Wampfler conductor rail range — significantly smaller than the 0811's 14.7 x 15.5mm profile — enabling multi-pole installations in space-constrained environments where standard conductor rail pole spacing cannot be achieved. The system accommodates any number of poles in monorail conveyor configurations with 2, 4, 6, 8, or 10-pole hanger clamp combinations, supports any rail layout including curved and ring arrangements, and is rated for indoor installation only. Collector insertion is from the side or bottom.
Primary US applications for the 0831 MultiLine fall into three categories:
High storage and automated storage and retrieval systems — where compact multipole conductor rail reduces the infrastructure footprint within racking structures and minimizes the clearance requirements of multi-rail single-pole alternatives.
Process and hall crane installations in manufacturing facilities — where simultaneous power and control circuit delivery in a single compact rail assembly simplifies runway wiring and reduces installation time relative to equivalent single-pole multi-rail configurations.
Transfer car systems in production and warehousing operations — where multipole conductor rail consolidates power and control circuits into a single low-profile assembly along the transfer car track, reducing track infrastructure complexity and ongoing maintenance requirements.
Crane-Controls.com's technical team provides pre-sale application support for 0815 system design, space constraint analysis, pole configuration, and component specification for compact curving US conductor rail installations. OSHA and ASME B30 compliant installations supported.
